The Hard Part of Upgrading Spark Versions Isn’t the Code

A few weeks ago AWS shipped the Spark Upgrade Agent, an AI agent that migrates Spark jobs to Spark 4.0. You point it at a repo, it rewrites deprecated APIs, adjusts for behavioral changes, updates the build for Scala 2.13, submits the result to an EMR cluster, and iterates on failures until the job runs. It handles both Scala and PySpark, and it works the way you'd hope an agent would: plan, transform, validate, repeat. The potential payoff is large - newer Spark versions have better performance and years of accumulated bug fixes.

It looks like a good tool and data teams looking into a Spark migration should consider it, but what we’ve found is that in the enterprise, rewriting code isn’t the main impediment to upgrading Spark workloads. Spark programs are part of complex pipelines, parts of which are poorly understood or maintained, and making changes to a sensitive system is inherently risky. There’s no guarantee that the output data will actually remain the same, and data integrity is the fundamental challenge of completing such a migration.

Several companies have written in detail about major Spark upgrades, and the data integrity challenge is a recurring theme.

Slack

Slack's migration from Spark 2 to Spark 3 took about a year across 60+ EMR clusters and 40+ teams. They saw some code-level breakage: `RAND()` in join keys became an `AnalysisException`, some casts that Spark 2 tolerated started failing, the `Greatest` function handled NULLs differently than its Hive counterpart. Validation was a much larger effort. For billing pipelines, Slack required exact matches, building test tables from production data on Spark 3 and running `EXCEPT` and `COUNT` comparisons in Trino against the Spark 2 outputs, with a Python framework for digging into every discrepancy. The discrepancies weren't all bugs. Non-deterministic row ordering, timestamp variations, and genuine semantic differences between Hive and Spark implementations all produce diffs that need to be investigated. Some are noise, some are real regressions.

Uber

Uber's version of this is bigger and more instructive. They migrated from Spark 2.4 to 3.3 with over two million Spark applications running daily. The code transformation was automated with Polyglot Piranha, their structural rewrite tool. It parses the source code into an AST, matches patterns, and applies transformation rules, including inserting legacy flags like `spark.sql.legacy.allowUntypedScalaUDF` where old behavior had to be preserved. This scaled well. The problem that shaped the whole project was stated plainly: "We had over 40,000 Spark apps, so we couldn't decentralize the data validation." No staging environment, no test cases, no way to ask every team to eyeball their own outputs.

So the flagship engineering artifact of Uber's Spark upgrade wasn't actually a code migrator but Iron Dome: a shadow-testing framework which runs the migrated job against production inputs, rewrites output paths at runtime so results land in staging instead of production, puts guardrails at the Hadoop FileSystem interface so a misrouted write can't touch real data, then compares the shadow output against the production run and only marks the job migrated when they agree.

Facebook

None of this is specific to the Spark 2-to-3 transition, or even to Spark versions. When Facebook moved Hive workloads onto Spark SQL back in 2017, they ran shadow pipelines writing to tables suffixed `_spark_shadow` so downstream jobs were never exposed, used count checks as a cheap first filter, and reached for full hash validation of outputs only reluctantly (because, as they put it, the hash validation was "sometimes even heavier than the query itself.") Funny enough, proving the new engine produced the same answer could cost more compute than producing the answer. They note that non-deterministic UDFs made validation hard, the same diff-adjudication problem Slack hit eight years later.

Takeaway

In the enterprise, migrations are rightfully considered risky projects that take time and incur risk. This is especially true in the age of AI given that the things that AI doesn’t necessarily deliver are also the riskiest parts of the migration - edge cases, data integrity, the long tail, etc. This isn’t to say that AI can’t help with building tooling for a migration, it clearly can, but usually an agent isn’t going to do the trick alone.

At Flarion, a major goal of ours is to give users the best possible performance and access to modern features without requiring a code migration. If you can get the benefits of Spark 4.2 while staying on Spark 3.4 then that’s a huge time save and reduction in risk. Of course, the data integrity problem doesn’t disappear, it’s now Flarion’s responsibility. One we’re happy to shoulder.

‍

Spark 4.2 was released in mid-July, and a lot of the attention went to the headline features: geospatial types, change data capture, vector search. Tucked into the performance section was a smaller item that we found particularly interesting. Arrow-optimized Python UDFs, and Arrow-based data exchange with Python in general, are now on by default.

One can consider this a mere config flip. The feature has existed since Spark 3.5. But defaults are how a platform tells you what it considers normal, and Spark just declared that the normal way to move data between the JVM and Python is Apache Arrow. It's worth walking through why that boundary was slow in the first place, what Arrow does about it, and what it changes for everything sitting underneath.

‍

What a Python UDF Actually Costs

PySpark has a split identity. The engine that executes your job runs on the JVM, and your UDF runs in a separate Python process, because that's where Python code has to run. Every batch of rows that passes through the UDF makes a round trip: out of the JVM, across a socket into the Python worker, through your function, and back.

Until now, the default way to make that trip was pickle. Each row was converted from Spark's internal representation into a Python object, serialized, sent across, deserialized, processed, and then the whole sequence ran again in reverse. One row at a time, one object at a time. The work is pure overhead. It exists because the two sides of the boundary represented the same data differently, and translation was the only way across.

For UDF-heavy jobs the translation regularly cost more than the function being called. It's one of the oldest pieces of PySpark folklore: keep your logic in built-in expressions if you can, because the moment you write a Python UDF, you pay a tax that has nothing to do with what the UDF does.

‍

What Arrow Brings to the Table

Apache Arrow is a specification for how tabular data is laid out in memory: columnar, in large contiguous buffers, with a defined binary layout for every type. The layout is the same regardless of which language or engine produced it. If two systems both hold data in Arrow format, one can hand the other a batch without converting anything, given that the bytes are already in the shape the receiver expects.

Applied to the Python boundary, this removes most of the tax. Instead of serializing rows into Python objects, the JVM sends Arrow batches, and the Python side reads them directly as columnar data. There is still a process boundary and still a copy across the socket, but the expensive part - turning every value into an object and back - is gone. Spark's own benchmarks for Arrow-optimized UDFs showed roughly 2x speedups on chained UDFs when the feature shipped in 3.5, with larger gains the more the workload was dominated by the boundary rather than the function.

The history of this feature tells you something about defaults. Arrow UDFs arrived as an opt-in in Spark 3.5. Spark 4.1 added Arrow-native UDF decorators that skip the pandas conversion entirely. With 4.2, Arrow is the default and pickle is the fallback. Everyone gets the faster boundary, including the large majority of users who never knew there was a flag.

‍

The Ecosystem Keeps Converging on Arrow

The UDF change is one instance of a pattern that has been running for years. `toPandas` and `createDataFrame` now use Arrow by default too, in the same release. Spark Connect streams query results to clients as Arrow batches. Outside of Spark: pandas can be backed by Arrow, Polars is built on it, DuckDB reads and writes it natively, DataFusion uses it as its internal memory model. When these systems exchange data with each other, more and more often no conversion happens, because both ends already speak the same format.

This is what a de facto standard looks like while it's forming. Nobody mandated Arrow; each project adopted it because interoperating through a shared memory layout is cheaper than maintaining pairwise converters. Every Spark release for the past several years has replaced another row-based boundary with an Arrow one, and there's no reason to expect the direction to reverse.

‍

What the Default Doesn't Change

It's worth being precise about what got faster. The boundary between the JVM and Python is now columnar. The engine on the JVM side of that boundary is the same one it was before — predominantly row-oriented, executing on the heap, one row at a time through most operators.

That produces a slightly odd shape for a typical PySpark job. The scan reads Parquet, which is columnar on disk. Spark turns it into rows to execute the joins and aggregations. At the UDF boundary, those rows are batched back into Arrow's columnar form, shipped to Python, processed, returned, and turned back into rows for whatever comes next. The data changes representation multiple times, and the fast columnar format only exists at the edges. Spark 4.2 made the edges cheap. The middle is where most of the job's time goes, and the middle didn't change.

Rewriting the executor is a different scale of undertaking than adopting Arrow at the boundaries, and the boundaries were a reasonable place to start. But the release defines the remaining gap fairly precisely: the format Spark now uses to talk to Python is not the format it uses to compute.

‍

Running the Middle on Arrow Too

That gap is where Flarion sits. Our engine executes Spark's operators - scans, joins, aggregations, and the rest - in native Rust code built on Apache Arrow and DataFusion, replacing the row-at-a-time JVM path for the parts of the plan it supports. Inside the engine, data stays in Arrow's columnar layout the whole way through. It goes in as a plugin on the Spark job you already have; unsupported operations fall back to Spark and run the way they always did.

Spark standardizing its boundaries on Arrow makes this arrangement steadily cleaner. When the engine hands data back to Spark, or Spark hands data to a Python worker, both sides increasingly agree on the memory layout, so the crossings that used to require translation become handoffs. Data moves between Spark's JVM and our engine through Arrow's C Data Interface without copying at all — a pointer to the buffers crosses the boundary, and the data stays where it is.

The UDF change is a preview of what that feels like, applied to one boundary. The excitement around it comes from removing translation overhead at a single crossing point. An Arrow-native engine applies the same idea to the execution itself: the scan produces Arrow, the join consumes Arrow, and the representation never changes because there's nothing to change it into.

‍

Summing Up

Spark 4.2's UDF change is a nice speedup, but the reason it caught our attention is what it says about direction. Spark is a conservative project and it doesn't change defaults lightly, because millions of jobs run on whatever the defaults are. When a project like that decides Arrow is how data should cross the Python boundary, it's acknowledging what the rest of the ecosystem already settled on. In short, the future is Arrow.

‍
